Suitable for FD30, FD60, FD90 and FD120 timber doors, and FD240 steel doors, up to 120kg weight.
Intumescent Hinge Pads MUST be used on fire doors for full compliance to BS EN 1634 & BS EN 1935. Sold in packs of 6 (enough for 3 hinges 1½ pairs).
Also available in other finishes.
Features
BS EN 1935 : 2002 Grade 13
Grade 201 stainless steel
102mm x 102mm x 3mm
Retro fit use on FD120 timber doors
For doors up to 120kg in weight
UKCA marked & CE marked
Certifire CF849
Finishes
SSS
Standards
Product Information
Website Category:
Door Hinges Selective Ironmongery Range
Website Sub-Category:
Fire rated hinges Heavy Duty hinges Parliament and projection hinges Ball Bearing hinges
Product Range:
Selective Ironmongery Range
Finish:
Satin Stainless Steel
Maximum Door Weight:
120kg
Satin Stainless Steel Heavy Duty Projection Ball Bearing Hinges 102mm x 102mm x 3mm
