Scrigno is the market leader in the production and sale of frames for concealed sliding doors. Their pre-assembled cassette complete with timber components reduces installation time and simplifies the installation process.

Pocket doors are designed to remove the unusable space within buildings. By removing the footprint created by traditional hinged doors, users can make the most of their space. With a typical space saving of 2.6m² per door compared to hinged doors, pocket doors are fast becoming the ideal solution where space is at a premium.

Pocket Door Systems are ideal for: Living areas, en-suites, office spaces and cloakrooms.

Features

  • FD30 Fire Rated System
  • Time saving pre-assembled pocket
  • Space saving
  • Simple installation
  • Suits Fire Doors 40-44mm thick
  • Max weight 120kg
  • Architrave free edgeless system
  • Cassettes suitable for 100mm stud/125mm finished wall from stock
  • Sides of metal box made of single sheet with corrugations strength
  • No frame deflection. Galvanized metal sheet construction, thickness 0.5 mm for the sides and rear, 0.8mm for the upper and lower profile. Side made with a single galvanized steel sheet corrugated vertically 100mm apart
  • With 60 screws for precise att. of plasterboard to frame
  • Single, Double, Fire door, Glass door for UK standard metric /imperial sizes available
  • Soft close & simultaneous opening solution available
  • White or natural wood jambs from stock available
  • 10 year warranty on track and sliding system
  • BS 476-22:1987 30 Minute Fire Test when fitted with a FD30 Fire Door
  • Slow Damper Unit max door weight 35kg
  • Automatic Self Closing Kit for FD30 max door weight 35kg.(Purchased separately)
  • Kit does not include door
Scrigno Pocket Door System – Single FD30 Fire Door Imperial Size
27" x 78"
Product code: FM351|0002N
£730.54 Ex VAT
Each
VAT
Scrigno Pocket Door System – Single FD30 Fire Door Imperial Size
30" x 78"
Product code: FM351|0003N
£730.54 Ex VAT
Each
VAT
Scrigno Pocket Door System – Single FD30 Fire Door Imperial Size
33" x 78"
Product code: FM351|0004N
£730.54 Ex VAT
Each
VAT
Scrigno Pocket Door System – Single FD30 Fire Door Imperial Size
36" x 78"
Product code: FM351|0005N
£730.54 Ex VAT
Each
VAT
FS30 Automatic Self Closing Kit (Must be used on fire doors)
For single pocket door system
Product code: 35173
£141.45 Ex VAT
Each
VAT
FD30 "Slow door down" Damper Unit
For single pocket door system
Product code: 35175
£75.04 Ex VAT
Each
VAT
